PV T Eco Carport 11.4 m × 3.3 m

An economical photovoltaic carport for two cars

The PV T Eco carport is a practical solution for individuals and businesses looking to make efficient use of their parking space while generating electricity from solar energy. Designed to accommodate two cars, it provides protection against weather conditions and allows photovoltaic panels to be installed on its structure.

Carport Eco – a solid structure at an economical price

The PV T Eco model combines an economical design with durability and reliable performance. Its structure is made from cold-formed S350GD steel and hot-rolled S275JR steel. Corrosion protection is provided by Magnelis® ZM310 coating, Z275 galvanization or hot-dip galvanizing, depending on the component.

The manufacturer offers a 25-year warranty on the Magnelis® coating and the structure.

Key benefits

• Space for two cars

• Possibility of installing photovoltaic panels

• Durable steel structure

• Corrosion protection adapted to individual structural components

• An economical solution for residential and commercial applications

Scope of supply

The kit includes the carport structure only.

The following are not included: photovoltaic panels, impact barriers, sealing system and guttering.

Technical specifications

• Model: PV T Eco

• Dimensions: 11.4 m × 3.3 m

• Number of photovoltaic panels: 18

• Panel dimensions: 1903 × 1134 × 30 mm

• Panel tilt angle: 10°/15°

Materials and corrosion protection

• Main structure: hot-rolled S275JR steel with hot-dip galvanizing

• Purlins: cold-formed S350GD steel with Magnelis coating or Z275 galvanization

• Magnelis® coating: ZM310

Wind and snow load parameters

• Wind zone: Zone 1, up to 22 m/s

• Snow load zones: Zones 1–4, up to 1.6 kN/m²

Warranty

• Components with Z275 galvanization: 1 year

• Hot-dip galvanized components: 2 years

• Magnelis coating: 25 years

• Structure: 25 years

Standards

• PN-EN 1090

• PN-EN 1990:2004

• PN-EN 1991-1-3

• PN-EN 1991-1-4

• PN-EN 1933-1-1:2006P

• PN-EN 1993-1-1-3:2008P

• PN-EN 1993-1-5:2008P

The PV T Eco carport is an economical and functional solution for anyone looking to combine covered parking with the potential to generate electricity from solar energy. Its steel construction and corrosion protection make it suitable for residential and commercial use.
