DC Isolating Switch, 4-pole for Photovoltaic Applications
The DC isolating switch with a 4-pole configuration is an essential solution for photovoltaic systems, ensuring effective protection and reliable operation. With a rated current of 16 A and a rated voltage of up to 1000 V DC, this switch is an ideal choice for photovoltaic installations with diverse requirements.
Key Features:
-
4-pole Configuration: The switch is designed to offer maximum flexibility and efficiency, able to handle various PV system configurations.
-
Compliance with Standards: It meets IEC/EN 60947-3 standards, confirming its high quality and adherence to safety regulations.
-
Optical Trip Indicator: Equipped with an optical trip indicator for quick identification of issues in the system.
-
Modular Design: The 4-module width on the rail makes installation and maintenance easier, offering flexibility and ease of use.
Electrical Parameters:
-
Rated Voltage: 1000 V DC
-
Rated Current: Up to 16 A
-
Number of Poles: 4
-
Short-circuit Breaking Capacity: Up to 33 kA
-
Maximum Power Dissipation of Fuse Insert: 4 W
-
Connected Load: 2.5 - 10 mm²
Mechanical Parameters:
-
Device Width: 4 modules on the rail
-
Device Height: 83 mm (89 mm with rail clip)
-
Frame Size: 45 mm
-
Mounting: Easy mounting on 35 mm DIN rail
-
Protection Degree: IP20
-
Fuse Dimensions: 10 x 38 mm
-
Weight: 0.07 kg per pole
The DC Isolating Switch is not only a protective component but also a key part of ensuring the safety and stability of photovoltaic systems. Thanks to its robust design and advanced features, it is an indispensable tool for professional photovoltaic installations.
